Aerospace Engineering Solutions (AES), a leading specialist in aircraft design and certification, is thrilled to announce the successful completion and approval from the European Union Aviation Safety Agency (EASA) for Supplemental Type Certificate (STC) No. 10085153. This STC enables a complete business-class only cabin reconfiguration on an Airbus A321 aircraft.

Headquartered in the UK, with additional operations in Spain and Ireland, AES’s Design Organisation Approval (DOA) team was contracted by beOnd, the world’s first premium leisure airline, to develop a modification that introduces a cabin layout using 34 business class seats, generating a 68-passenger seating configuration. The lie-flat seat motion system is a standout feature in the narrow-body aircraft market.

Key modifications include:

  • Installation of Optimares Vivaldi lie-flat business class seats
  • Integration of the seat motion power system
  • Installation of 110V AC and USB Type C In-Seat Power Supply System
  • Rearrangement of cabin monuments
  • Door 3 exit type re-assigned from Type I to Type III
  • Rearrangement of Passenger Service Units (PSUs)
  • Reconfiguration of emergency equipment and emergency path lighting
  • Updated placards
  • New carpet and cabin attendant seat covers
  • On-site cabin inspections

In addition to the interior reconfiguration, AES also provided the EASA-approved Part 21J technical data package to accomplish beOnd’s stunning signature dark grey and copper livery.

Commenting on this achievement, Andrew Dolby, Director at Aerospace Engineering Solutions, said:

“This latest STC approval reflects our commitment to excellence and reinforces our position as a leader in aircraft cabin reconfigurations. Our team demonstrated exceptional resourcefulness and dedication, overcoming challenges related to material and parts procurement, all while working within a tight time schedule to ensure that the modification was completed and approved on time for our customer. We are thrilled to have partnered with beOnd on their new aircraft and deliver a configuration that will enhance the passenger experience, and we wish them all the success.

“Our vast scope of approval and highly experienced team in cabin interiors, structures, and avionics allows us to provide our customers with any cabin configuration for their fleet.”

Tero Taskila, CEO & Chairman at beOnd, said:

“We are happy to have received the STC for our A321 aircraft, marking the addition of the second aircraft to our growing fleet. The expertise and professionalism of the AES team have been invaluable in transforming the beOnd vision from concept to reality, supporting our journey of expansion. A special thank you to Andrew and the entire AES team for their outstanding partnership. As we continue to grow, we look forward to working with them again in the future.”

beOnd Airbus A321



beOnd Airbus A321

We are excited to announce that Aerospace Engineering Solutions has been granted EASA-approved STC No. 10084621. This modification introduces a new cabin layout featuring 24 business class seats and 250 economy class seats, resulting in a 274-passenger seating configuration on the Airbus A330 aircraft. With the increasing demand for transoceanic flights, AES is delighted to support the aviation community with long-haul wide-body projects.

Furthermore, the STC integrates Panasonic’s lightest and lowest power IFEC system, eXLite, into the existing eX2 system on the aircraft. This integration provides operators with an updated IFEC system.

Another milestone achieved by our DOA team. Our team overcame the following challenges to get the modification approved on time for our customer, with materials and parts procurement:

  • Seat re-pitch and installation
  • IFE and seat-to-seat cabling and raceway installation to accommodate the new layout
  • Oxygen pipeline and PSU rearrangement
  • Emergency equipment and placards rearrangement through concurrent minor modifications to speed up the approval process and minimise costs

A special mention to the AES team, both UK and Spanish offices, and our partners Aviation Scouts, Panasonic Avionics Corporation, Aviation Graphix, 21Aero and Jetglow Aircraft Refurbishments, without whom this project would not have succeeded as it has. Thank you very much.

Aerospace Engineering Solutions (AES) has collaborated with numerous airlines worldwide, providing EASA-approved Part 21J DOA support for exterior liveries and mandatory markings. Our extensive experience enables us to offer services for new and existing liveries, airline rebranding, and retro and promotional liveries.

Celebrating success with Brussels Airlines

We are proud to be part of this fantastic project for Brussels Airlines on ‘Amare’, the latest Belgian Icon! Our team provided the EASA-approved Part 21J exterior livery drawings for the Airbus A320neo. On April 26th, 2024, Amare (reg OO-SBB) took its inaugural revenue flight adorned with the captivating livery, symbolising the renowned music festival Tomorrowland.

Honouring heritage with TUI’s 50th anniversary livery

Another significant example showcasing our expertise is the TUI Boeing 737-8Max livery, designed to commemorate its 50th anniversary. Inspired by the airline’s rich history and vintage aesthetics, our team played a pivotal role in creating this livery, providing the EASA-approved Part 21J exterior drawings. We are honoured that TUI entrusted us, and we extend our warmest congratulations to them for this milestone.



If you have a requirement for aircraft livery design, contact us today!

Contact Us

Please join us at the global marketplace for the world’s cabin interiors and inflight entertainment industry. Aircraft Interiors Expo is the professional platform where airlines, designers, engineers, specifiers, and manufacturers come together to share, collaborate, and find practical and innovative solutions.

We will be exhibiting from 28–30 May 2024, where our industry-leading technical experts will be on hand to discuss all your certified aerospace design and engineering requirements. Explore our comprehensive Part 21J DOA (Design Organisation Approval) services and wide range of aerospace products. Come and visit us at booth 7B72.

Book a meeting with AES

Contact Us

Is your Boeing 737NG cabin configurations in compliance with EASA regulations?

In response to the Certification Memorandum CM–21.A–CS–001 Issue 02, titled “Classification Of Design Changes To Cabin Interiors Of Large Aeroplanes,” released by EASA in April 2021, AES has successfully secured six Supplemental Type Certificates (STCs) for various seat type configurations on the Boeing 737NG, covering both 186 and 189 passenger configurations. Notably, the most recent STC covers the Safran Z100 series in a 189 configuration (STC Nr 10083547). AES is actively pursuing additional STCs, with several applications currently in progress.

The Certification Memorandum clarifies classification of changes to Cabin Interiors including the installation of seats that require a compliance statement against CS25.562, focusing on Emergency Landing Dynamic Conditions. It’s worth noting that this requirement has been a longstanding part of EASA Part 21 Appendix A of GM 21.A.91. However, with the release of CM–21.A–CS–001, EASA has clarified and reinforced the classification process for such changes, superseding past practices.

A key aspect highlighted in accordance with EASA B737 Type Certificate Data Sheet (TCDS) IM.A.120 is that most seating configurations for the B737NG family must meet the requirements for JAR25 Chapter 13, excluding certain clauses. This mandates the classification of these changes as Major (STC). It is important to mention the requirement provided in CS26.60 (Additional Airworthiness Specifications), which requires dynamically tested seats to be installed in configurations manufactured post-26th February 2021 to be compliant with CS25.562.

AES remains committed to delivering aerospace engineering solutions that not only meet but exceed regulatory requirements, ensuring the highest standards of safety and compliance in the aviation industry. For further details on these achievements, interested parties are encouraged to contact us below.

Aerospace Engineering Solutions maintains excellence in DOA audits with the European Union Aviation Safety Agency (EASA) and General Civil Aviation Authority (GCAA). We are pleased to report that both audits were highly successful, further solidifying AES’s standing as a mature and competent DOA. The Design Organisation Approval Team Leader (DOATL) specifically commended AES, stating:

Special merit should be mentioned for the mature methodology in place and the technical competence shown by the team in our scope of activity.

These audits represent a continuous achievement for the company and validate the effectiveness of our Design Management System in ensuring that our approvals are kept up to date and aligned with the latest regulations. Please check our about page for more information.

Aerospace Engineering Solutions introduces a minor modification for portable ELT installation to address EASA requirements with non-rechargeable lithium batteries (NRLB), eliminating the need for STC applications.

Meeting EASA requirements

EASA CAT.IDE.A.280(a) states that all aircraft with a Maximum Operational Passenger Seating Configuration (MOPSC) exceeding 19 must be equipped with at least one automatic ELT, with the provision of two for aircraft with Certificates of Airworthiness (CofA) issued before July 1, 2008. Automatic ELTs might be portable with lithium batteries as part of their design. Lithium batteries ETSO C142b non-compliant installation requires an STC application.

Minor modification for maximum impact

AES offers a minor modification package compatible with all aircraft types. Our comprehensive solution includes engineering support, portable ELT (Oriola) compliant with ETSO C142b, and an installation kit comprising bracketry and placards designed to meet NRLB installation requirements.

Benefits for operators and lessors

The beauty of the AES solution lies in its simplicity. Operators and leasing companies can now fully comply without the STC application process. This minor modification not only ensures compliance but also offers flexibility for fleet-wide adaptations or individual aircraft adjustments in the most cost-effective manner.

Minor Modification for Portable ELTs

To learn more about our solution and how it can benefit your operations, contact us today!

Aerospace Engineering Solutions has successfully obtained EASA approved Supplemental Type Certificates (STCs) for Boeing 737NG galley replacement.

Galley installations (or replacement galleys), whether driven by factors such as damage beyond economic repair, alternative arrangement needs, or operational requirements for new operators, are essential to aircraft functionality. Sometimes, operators require specific galley insert arrangements that are difficult or impossible to achieve through galley modification. In such cases, the only viable solution is to replace the unit. AES not only prepares the engineering but also provides the necessary parts, including any structural and electrical provisions. We go the extra mile, performing any associated changes in the cabin, particularly in the areas local to the galley if required. This ensures a seamless transition, even if a new G2 galley, for instance, is larger or smaller than the original unit.

Our latest STCs provide the perfect solution:

EASA STC No. 10080018 – G1 and G2 galley replacement
EASA STC No. 10080919 – G4 galley replacement
EASA STC No. 10081077 – G7 galley replacement

Aidan O’Leary, Director of Engineering – Ireland, comments:

“We proudly lead the way in aerospace engineering, and our latest EASA STCs for the replacement/installation of Boeing 737NG family galleys are a testament to our unwavering commitment to revolutionizing aircraft interiors. As an industry leader in certified aerospace design and engineering, AES has achieved a remarkable milestone of over 3,000 successful interior cabin modifications. We are dedicated to delivering high-quality, cost-effective solutions that continuously adapt to the dynamic demands of the aviation industry.”

STC for replacement of G1 and G2 Galleys - B737NGSTC for replacement of G4 Galley - B737NGSTC for replacement of G7 Galley - B737NG

Explore our comprehensive Part 21J DOA services and wide range of aerospace products.

Contact us below to arrange a meeting

Aerospace Engineering Solutions and Air Worthy, Italian Continuing Airworthiness Management Organisation (CAMO), are delighted to announce a DOA & CAMO partnership.

Under the combined expertise of AES and Air Worthy, this venture seamlessly integrates the strengths of both companies in aircraft safety, design, and modifications. By harnessing AES’s unparalleled EASA Part 21J scope of approval and drawing on Air Worthy’s unwavering commitment to continued airworthiness, we’re paving the way for a streamlined process in serving airlines and aircraft leasing companies with their aircraft modification needs.

A formalised meeting took place at Air Worthy’s office in Lodi, Italy, on 11 September 2023, where both companies came together to chart a path toward excellence in aerospace engineering services. Present were notable representatives from AES: Anton Heissig, Director and Lola Lahoz, Deputy of Head of Airworthiness, and from Air Worthy: Gabriele Brescianino, Accountable Manager, Lucia Soffientini, Continuing Airworthiness Manager, and Samantha Orsini, Customer Relationship Manager.

Samantha Orsini kicked off the meeting with an insightful presentation about Air Worthy and a comprehensive dive into Air Worthy’s history, unparalleled CAMO services, team structure, and unwavering commitment to excellence, led by Gabriele Brescianino and Lucia Soffientini.

One common thread that ran through the meeting was the shared mission of both companies – a relentless commitment to delivering high-quality services with proven integrity and attention to detail. Quality assurance is a top priority for AES and Air Worthy, a cornerstone of their partnership.

The highlight of the meeting was the vision of a partnership gearing up to offer a comprehensive CAMO+DOA “package” to their customers, delivering a one-stop solution for their aviation needs. Already taking tangible form, the first collaborative project to kick off soon, where Air Worthy will tap into AES’s DOA expertise to support Avionics modifications, exemplifying this partnership’s proactive and dynamic approach.

Don’t hesitate to contact us if you need DOA and CAMO services for your aircraft fleet and would like to learn more about our collaboration services.

Please join us at MRO Europe 2023. Attracting over 9,000 attendees, it is the largest event of its kind in the region and is a unique opportunity to connect with the entire aviation aftermarket. The two-day exhibition features over 450 exhibitors from around the world, representing all levels of the airline supply chain.

Aerospace Engineering Solutions (AES), a leading EASA Part 21J Design Organisation Approval (DOA) holder will be exhibiting from 18–19 October 2023 with our industry leading technical experts on hand to discuss all your certified aerospace design and engineering requirements. Join us at MRO Europe 2023 at the RAI, Amsterdam, The Netherlands on the Shannon Village Stand 1354.

Explore our comprehensive Part 21J DOA (Design Organisation Approval) services and wide range of aerospace products.
